P5.js in Instance Mode

For the uninitiated, P5 is a JavaScript implementation of the Processing programming language. For the Very Olds among us, Processing is a bit like Logo. That is: a simple language geared towards producing art.

Every so often I give P5 a poke or two because I find generative art (the non-AI kind) fascinating. Usually I do this on CodePen (here’s a fractal tree), but I really want to roll it into this site.

However, P5 is written with the basic learner in mind and there’s a lot of stuff set up with the expectation that you’re just going to set up a P5-exclusive project and go. It uses a classic mode of JavaScript development, putting everything in a global space and depending on correct sequencing of source-file downloads. Which is nice, but it means the simple approach is hostile to integration with other frameworks, build tools, and JavaScript.

Fortunately, P5 has an “instance mode” and a npm package, but getting these to work required a bit of digging. I don’t think either is mentioned in the official documentation. You have to go look up instance mode in their wiki.

OK, what I did

This site is built using Astro, but I think this process is going to be pretty similar if you have some sort of build process. This assumes you have an existing node project.

Add to your project with NPM or similar; for example: npm i p5. You can then import into your source files with import p5 from "p5".

I use TypeScript¹, so at this point my project started barking at me about missing types, but the error message was a new one on me:

Could not find a declaration file for module 'p5'. '[...]/node_modules/p5/dist/app.js' implicitly has an 'any' type.

There are types at '[...]//node_modules/p5/types/p5.d.ts', but this result could not be resolved when respecting package.json "exports". The 'p5' library may need to update its package.json or typings.

I solved this by adding a separate type project (npm i --save-dev @types/p5). It seems to work, but there’s probably a better way.

When you import p5 from "p5" you get a class you can instantiate:

import p5 from "p5"

const sketch = new p5((p5) => { [...] })

The constructor accepts a single argument function that you can then use to call all of P5’s methods. It will also take a second argument: an element to use as a render target.

Here’s a simple, complete example:

import p5 from "p5";

// For clarity's sake, I like to store the sketch in a variable
const sketch = (p: p5) => {
  p.setup = () => {
    p.createCanvas(200, 200);
    p.background(128);
  };

  p.draw = () => {
    p.stroke("rebeccapurple");
    p.strokeWeight(50);
    p.point(100, 100);
  };
};

const target = document.getElementById("Target");

if (target) {
  new p5(sketch, target);
}

That will get you this:

In “global” mode, P5 looks for window.setup() and window.draw() functions. It’s not going to find those, so it will then switch to “instance” mode and run the setup() and draw() functions defined on the P5 instance created by the constructor.

There’s no need to kick off the animation. P5 will start automatically, just as it does in global mode.

Working with Classes

If you want to follow Daniel Shiffman’s advice and turn your animation elements into separate classes, you’ll need to pass the P5 instance to your class constructors for them to have access:

class Walker {

	constructor(p) {
		this.x = p.width / 2;
		this.y = p.height / 2;
		this.p = p;
	}

	show() {
		this.p.stroke(255);
		this.p.strokeWeight(10);
		this.p.point(this.x, this.y);
	}

  [...]
}

Shiffman doesn’t do this in his examples because he still has P5 running in global mode, so all of the P5 functions are defined in the global space.

Anyway, I hope this helps someone, somewhere, assuming a search engine chooses to show my website at any point. 🤣
